Ultrasonic Sensors

Frequencies above the human hearing threshold of approx. 20 kHz are referred to as ultrasound. Ultrasonic technology can be used for continuous, non-contact and maintenance-free distance measurement as well as for level measurement of liquids, pastes, slurries and powdery to lumpy bulk materials and for flow measurement.

There are 10 of 41 products shown.

TC0223-000

  • Type: AK2
  • Frequency [kHz]: 55.5 kHz
  • Sensitivity: ≥36
  • Decay time [mS]: ≤2.20
  • Directivity [X° / Y°]: X 90° Y45°
  • Size [Фmm x H mm]: Ф 15.5 H 9.0
  • Automotive: no
  • Manufacturer: Audiowell
TC0223-000

TO0139-000 & TO0140-000

  • Type: Open-type sensor transmitter and reciever
  • Frequency [kHz]: 40 kHz
  • Sound Pressure Level: ≥117
  • Sensitivity: ≥-67
  • Directivity [X° / Y°]: 90°
  • Size [Фmm x H mm]: Ф8.0 H 6.0
  • Automotive: no
  • Manufacturer: Audiowell
TO0139-000 & TO0140-000

TO0002-000 & TO0001-000

  • Type: Open-type sensor transmitter and reciever
  • Frequency [kHz]: 40 kHz
  • Sound Pressure Level: ≥115
  • Sensitivity: ≥-60
  • Directivity [X° / Y°]: 80°
  • Size [Фmm x H mm]: Ф16 .0 H 12.2
  • Automotive: no
  • Manufacturer: Audiowell
TO0002-000 & TO0001-000

TK0158-000

  • Type: Automotive intelligent sensor
  • Frequency [kHz]: 55.5 kHz
  • Ring time [ms]: ≤1.50
  • Directivity [X° / Y°]: X 90° Y 45°
  • Automotive: no
  • Manufacturer: Audiowell
TK0158-000

TK0163-000

  • Type: Automotive intelligent sensor
  • Frequency [kHz]: 55.5 kHz
  • Ring time [ms]: 1.0~1.45
  • Directivity [X° / Y°]: X 90° Y 45°
  • Automotive: no
  • Manufacturer: Audiowell
TK0163-000

UP0152-000

  • Type: Ultrasonic Rangefinder
  • Frequency [kHz]: 40 kHz
  • Measuring range [mm]: 20~2500
  • Automotive: no
  • Manufacturer: Audiowell
UP0152-000

TC0120-001

  • Type: UPA
  • Frequency [kHz]: 48 kHz
  • Sensitivity: 500~800μS
  • Decay time [mS]: ≤2.20
  • Directivity [X° / Y°]: X 65° Y 65°
  • Size [Фmm x H mm]: Ф15.5 H 9.0
  • Automotive: no
  • Manufacturer: Audiowell
TC0120-001

TO0119-001 & TO0120-001

  • Type: Open-type sensor transmitter and reciever
  • Frequency [kHz]: 40 kHz
  • Sound Pressure Level: ≥113
  • Sensitivity: ≥-63
  • Directivity [X° / Y°]: 80°
  • Size [Фmm x H mm]: Ф10.0 H 7.2
  • Automotive: no
  • Manufacturer: Audiowell
TO0119-001 & TO0120-001

AU0009-001

  • Type: Ultrasonic Rangefinder
  • Frequency [kHz]: 60 kHz
  • Measuring range [mm]: 20~350
  • Automotive: no
  • Manufacturer: Audiowell
AU0009-001

UM0034-002

  • Type: Ultrasonic Rangefinder
  • Frequency [kHz]: 60 kHz
  • Measuring range [mm]: 20~1000
  • Automotive: no
  • Manufacturer: Audiowell
UM0034-002
