Electromagnetic transducer

Overview of the advantages of Electromagnetic SMD Transducer:

  • Smallest Transducer (AC driven) available 5x5x2mm
  • Max SPL at low voltage
  • SMD reflow solderable
  • Wider frequency range than Piezo sounders
  • Ideal for limited space and multiple frequency applications like kitchen devices, medical- and health care accessories, cellular phones, PDS, etc.
  • Sound solutions for automotive applications on request

There are 10 of 21 products shown.

FDYX-0520S-03

  • Length [mm]: 5 mm
  • Width [mm]: 5 mm
  • Height [mm]: 2 mm
  • Rated Voltage [V]: 3 V
  • Sound Output at 10cm [dB]: 75 dB
  • Resonant Frequency [Hz]: 4,000 Hz
  • Manufacturer: Qinlon
FDYX-0520S-03

FDYX-0530S-03

  • Length [mm]: 5 mm
  • Width [mm]: 5 mm
  • Height [mm]: 3 mm
  • Rated Voltage [V]: 3 V
  • Sound Output at 10cm [dB]: 78 dB
  • Resonant Frequency [Hz]: 4,000 Hz
  • Manufacturer: Qinlon
FDYX-0530S-03

YX0725S-03

YX0725S-03

FDYX-801S-0327

  • Length [mm]: 8.5 mm
  • Width [mm]: 8.5 mm
  • Height [mm]: 3 mm
  • Rated Voltage [V]: 3 V
  • Rated Current [mA]: 50 mA
  • Sound Output at 10cm [dB]: 85 dB
  • Resonant Frequency [Hz]: 2,731 Hz
  • Manufacturer: Qinlon
FDYX-801S-0327

YX0725S-05

YX0725S-05

FDYX-801S-0330

  • Length [mm]: 8.5 mm
  • Width [mm]: 8.5 mm
  • Height [mm]: 3 mm
  • Rated Voltage [V]: 3 V
  • Rated Current [mA]: 50 mA
  • Sound Output at 10cm [dB]: 85 dB
  • Resonant Frequency [Hz]: 3,000 Hz
  • Manufacturer: Qinlon
FDYX-801S-0330

FDYX-801S-0527

  • Length [mm]: 8.5 mm
  • Width [mm]: 8.5 mm
  • Height [mm]: 3 mm
  • Rated Voltage [V]: 5 V
  • Rated Current [mA]: 50 mA
  • Sound Output at 10cm [dB]: 85 dB
  • Resonant Frequency [Hz]: 2,731 Hz
  • Manufacturer: Qinlon
FDYX-801S-0527

LF-MT05A03

  • Length [mm]: 5 mm
  • Width [mm]: 5 mm
  • Height [mm]: 2 mm
  • Rated Voltage [V]: 3.6 V
  • Rated Current [mA]: 130 mA
  • Sound Output at 10cm [dB]: 73 dB
  • Resonant Frequency [Hz]: 4,000 Hz
  • Manufacturer: Ariose
LF-MT05A03

LF-MT05B01

  • Length [mm]: 5 mm
  • Width [mm]: 5 mm
  • Height [mm]: 3 mm
  • Rated Voltage [V]: 3 V
  • Rated Current [mA]: 110 mA
  • Sound Output at 10cm [dB]: 75 dB
  • Resonant Frequency [Hz]: 4,000 Hz
  • Manufacturer: Ariose
LF-MT05B01

LF-MT08SB36

  • Length [mm]: 8.5 mm
  • Width [mm]: 8.5 mm
  • Height [mm]: 4 mm
  • Rated Voltage [V]: 3.6 V
  • Rated Current [mA]: 100 mA
  • Sound Output at 10cm [dB]: 85 dB
  • Resonant Frequency [Hz]: 2,700 Hz
  • Manufacturer: Ariose
LF-MT08SB36
