DC/DC modules non-isolated

MPS Power Modules offer superior performance and size advantages when compared to other industry leading solution. The monolithic design allows for faster switching frequency, which leads to ultra fast transient response and size reduction. The DC/DC modules integrate inductors, FETs, compensation, and other passive components into a single package to simplyfy the design process.

Applications

  • All electric and electronic devices, where a DC voltage transformation is needed
  • Because of the cheapness of the parts an assignment is profitable especially for mass-production
  • Power supply with multipart outputs

There are 10 of 87 products shown.

mEZDPD3603A-0001

  • Package: DIP
  • Vin [V]: 4.5 V ... 36 V
  • Vout [V]: 0.6 V ... 12 V
  • Regulated Outputs: 1
  • Iout max. [A]: 3 A
  • fsw [kHz]: 500 kHz ... 2,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
mEZDPD3603A-0001

MPM3683-10

  • Package: LGA-29
  • Vin [V]: 2.7 V ... 16 V
  • Vout [V]: 0.6 V ... 5.5 V
  • Regulated Outputs: 1
  • Iout max. [A]: 10 A
  • fsw [kHz]: 600 kHz ... 1,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3683-10

MPM3695-100

  • Package: BGA
  • Vin [V]: 3.3 V ... 16 V
  • Vout [V]: 0.5 V ... 3.3 V
  • Regulated Outputs: 1
  • Iout max. [A]: 100 A
  • fsw [kHz]: 400 kHz ... 1,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3695-100

MPM3695-25

  • Package: QFN-59
  • Vin [V]: 3 V ... 16 V
  • Vout [V]: 0.5 V ... 5.5 V
  • Regulated Outputs: 1
  • Iout max. [A]: 20 A
  • fsw [kHz]: 400 kHz ... 1,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3695-25

MPM3690-30A

  • Package: BGA
  • Vin [V]: 4 V ... 16 V
  • Vout [V]: 0.6 V ... 3.3 V
  • Regulated Outputs: 2
  • Iout max. [A]: 18 A
  • fsw [kHz]: 400 kHz ... 1,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3690-30A

MPM3690-30B

  • Package: BGA
  • Vin [V]: 4 V ... 16 V
  • Vout [V]: 0.6 V ... 3.3 V
  • Regulated Outputs: 1
  • Iout max. [A]: 36 A
  • fsw [kHz]: 400 kHz ... 1,000 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3690-30B

MPM3683-7

  • Package: QFN-28
  • Vin [V]: 2.7 V ... 16 V
  • Vout [V]: 0.6 V ... 5.5 V
  • Regulated Outputs: 1
  • Iout max. [A]: 10 A
  • fsw [kHz]: 480 kHz ... 1,150 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
MPM3683-7

mEZD71201A-A

  • Package: SiP
  • Vin [V]: 4.5 V ... 24 V
  • Vout [V]: 1 V ... 1 V
  • Regulated Outputs: 1
  • Iout max. [A]: 1.2 A
  • fsw [kHz]: 400 kHz ... 400 kHz
  • PG: no
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
mEZD71201A-A

mEZD71210A-A

  • Package: SiP
  • Vin [V]: 4.5 V ... 17 V
  • Vout [V]: 1 V ... 1 V
  • Regulated Outputs: 1
  • Iout max. [A]: 10 A
  • fsw [kHz]: 500 kHz ... 500 kHz
  • PG: yes
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
mEZD71210A-A

mEZD71203A-A

  • Package: SiP
  • Vin [V]: 5 V ... 24 V
  • Vout [V]: 1 V ... 1 V
  • Regulated Outputs: 1
  • Iout max. [A]: 3 A
  • fsw [kHz]: 400 kHz ... 400 kHz
  • PG: no
  • Tj [°C]: -40 °C ... 125 °C
  • Manufacturer: MPS
mEZD71203A-A
Package

Vin [V]

Vout [V]

Output [No.]

Iout max. [A]

fsw [kHz]

I2C Interface

PG

Operating Junction Temp Range [°C]

Contact
