Optocouplers

A photocoupler optically links, via a transparent isolating material, an infrared LED and a photodetector within one housing. Usually this detector is a phototransistor or a photodiode with some additional amplifiers. These devices are used for galvanic separation and protection of the inputs of switching power supplies, telecommunications equipment and household appliances. Beside that the manufacturers offer Intelligent Power Module-, Photovoltaic- and MOSFET/IGBT Gate Drive Optocoupler.
The optocouplers of the manufacturers CT Micro, Everlight and Cosmo are approved according to the most important safety approvals like VDE, UL,.. Everllight also offers AEC-Q102 certified optocouplers for automotive applications.

Features

  • DIL, SMD, Mini-flat (SOP) and SSOP-housing
  • Single- and multi-channel-types available
  • Isolating voltages up to 8.200V
  • Curent transfer ratios from 7-15000%
  • High-speed couplers with data rates up to 10Mbit/s
  • UL, VDE and TUV approved
  • REACH & RoHS compliant

There are 10 of 140 products shown.

KP5010

  • Package: SMD 6, DIP 6
  • Output Type: Darlington
  • Input: DC
  • VCEO [V]: 300 V
  • VISO [V]: 5,000 V
  • CTR [%]: 600 % ... 9,000 %
  • Manufacturer: Cosmo
KP5010

KP6010

  • Package: SMD 6, DIP 6
  • Output Type: Transistor
  • Input: AC
  • VCEO [V]: 60 V
  • VISO [V]: 5,000 V
  • CTR [%]: 60 % ... 600 %
  • Manufacturer: Cosmo
KP6010

KP4010

  • Package: SMD 4, DIP 4
  • Output Type: Darlington
  • Input: DC
  • VCEO [V]: 300 V
  • VISO [V]: 5,000 V
  • CTR [%]: 600 % ... 9,000 %
  • Manufacturer: Cosmo
KP4010

KP3040

  • Package: SMD 16, DIP 16
  • Output Type: Transistor
  • Input: AC
  • VCEO [V]: 60 V
  • VISO [V]: 5,000 V
  • CTR [%]: 60 % ... 600 %
  • Manufacturer: Cosmo
KP3040

KP2110

  • Package: SMD 6, DIP 6
  • Output Type: Transistor
  • Input: DC
  • VCEO [V]: 60 V
  • VISO [V]: 5,000 V
  • CTR [%]: 60 % ... 600 %
  • Manufacturer: Cosmo
KP2110

KP1020

  • Package: SMD 8, DIP 8
  • Output Type: Transistor
  • Input: DC
  • VCEO [V]: 60 V
  • VISO [V]: 5,000 V
  • CTR [%]: 50 % ... 600 %
  • Manufacturer: Cosmo
KP1020

K3010

  • Package: SMD 4, DIP 4
  • Output Type: Transistor
  • Input: AC
  • VCEO [V]: 60 V
  • VISO [V]: 5,000 V
  • CTR [%]: 60 % ... 600 %
  • Manufacturer: Cosmo
K3010

K1010W

  • Package: SMD 4, DIP 4
  • Output Type: Transistor
  • Input: DC
  • VCEO [V]: 80 V
  • VISO [V]: 5,000 V
  • CTR [%]: 100 % ... 600 %
  • Manufacturer: Cosmo
K1010W

K1010T

  • Package: SMD 4, DIP 4
  • Output Type: Transistor
  • Input: DC
  • VCEO [V]: 80 V
  • VISO [V]: 5,000 V
  • CTR [%]: 100 % ... 600 %
  • Manufacturer: Cosmo
K1010T

H11L3

  • Package: SMD 6, DIP 6
  • Output Type: Schmitt Trigger (High Speed)
  • Input: DC
  • VISO [V]: 5,000 V
  • CTR [%]: ...
  • Manufacturer: CT Micro
H11L3
Package

Output Type

Input

If [mA]

Vceo [V]

Vcc [V]

Ic [mA]

Viso [V]

CTR [%]

Data Rate [Mbit/s]

CMR [V/µs]

tr [µs]

tf [µs]

tphl [ns]

tplh [ns]
