TDK-Micronas

TDK-Micronas ist das Kompetenzzentrum für Magnetfeldsensoren und CMOS-Integration innerhalb der TDK Gruppe.

TDK-Micronas verfügt über mehr als 25 Jahre Erfahrung in der Herstellung von Halbleitern für Sensor- und Aktuator-Lösungen. Teilweise erfolgt die Fertigung in eigenen Fertigungsstätten in Deutschland. Im Jahr 1993 gelang es dem Unternehmen als Erstem einen Hall-Effekt-Sensor in CMOS-Technologie zu fertigen. Seitdem hat TDK-Micronas insgesamt über sechs Milliarden Hall-Sensoren an den Automobil- und Industriemarkt ausgeliefert. Die operative Zentrale befindet sich in Freiburg im Breisgau. Viele Produkte werden als ASIL-Ready angeboten.

Derzeit beschäftigt TDK-Micronas rund 1.000 Mitarbeiter.

Produktportfolio

  • Hall-Schalter
  • lineare Hall-Sensoren
  • magnetische Winkelsensoren
  • programmierbare Hall-Sensoren
  • Stromsensoren
  • Programmiertools

Geeignete Anwendungen

  • Automotive
  • weiße Ware
  • Industrie Elektronik
  • Consumer Elektronik





Es werden 10 von 70 Produkten angezeigt.

HAR3796

  • Technology: Hall
  • Sensor Type: 2D Angular Sensor Dual Die
  • Programmable: ja
  • Magnetic Field Range [mT]: 20 to 100
  • Supply Voltage Range [V]: tbd
  • Temp. Range [C°]: –40 to 170
  • Package: SOIC-8
  • Hersteller: TDK-Micronas
HAR3796

HAR3797

  • Technology: Hall
  • Sensor Type: 2D Angular Sensor Dual Die
  • Programmable: ja
  • Magnetic Field Range [mT]: 20 to 100
  • Supply Voltage Range [V]: tbd
  • Temp. Range [C°]: –40 to 170
  • Package: SOIC-8
  • Hersteller: TDK-Micronas
HAR3797

HAL1501 Hall-Effect Switch BipolarType 3-Wire TO-92UT AEC-Q100

  • Technology: Hall
  • Polarity: Bipolar
  • Swichting Points [mT] [Bon;Boff]: 0.4; –0.4
  • Output: Open-drain (3-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23-5
  • Hersteller: TDK-Micronas
HAL1501 Hall-Effect Switch BipolarType 3-Wire TO-92UT AEC-Q100

HAL1502 Hall-Effect Switch Latching Type 3-Wire SOT23 AEC-Q100

  • Technology: Hall
  • Polarity: Latching
  • Swichting Points [mT] [Bon;Boff]: 2.5;-2,5
  • Output: Open-drain (3-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23
  • Hersteller: TDK-Micronas
HAL1502 Hall-Effect Switch Latching Type 3-Wire SOT23 AEC-Q100

HAL1509 HAL1509 Hall-Effect Switch Unipolar inverted Type 3-Wire AEC-Q100

  • Technology: Hall
  • Polarity: Unipolar inverted
  • Swichting Points [mT] [Bon;Boff]: 3.7; 5.5
  • Output: Open-drain (3-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23, TO92UA
  • Hersteller: TDK-Micronas
HAL1509 HAL1509 Hall-Effect Switch Unipolar inverted Type 3-Wire AEC-Q100

HAL1508 Hall-Effect Switch Unipolar Type 3-Wire AEC-Q100

  • Technology: Hall
  • Polarity: Unipolar
  • Swichting Points [mT] [Bon;Boff]: -5.5;-3.7
  • Output: Open-drain (3-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23, TO92UA
  • Hersteller: TDK-Micronas
HAL1508 Hall-Effect Switch Unipolar Type 3-Wire AEC-Q100

HAL1563 Hall-Effect Switch Unipolar inverted Type 2-Wire AEC-Q100

  • Technology: Hall
  • Polarity: Unipolar inverted
  • Swichting Points [mT] [Bon;Boff]: 7.6; 9.4
  • Output: Current-source (2-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23, TO92UA
  • Hersteller: TDK-Micronas
HAL1563 Hall-Effect Switch Unipolar inverted Type 2-Wire AEC-Q100

HAL1562 Hall-Effect Switch Latching Type 2-Wire AEC-Q100

  • Technology: Hall
  • Polarity: Latching
  • Swichting Points [mT] [Bon;Boff]: 12; -12
  • Output: Current-source (2-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23, TO92UA
  • Hersteller: TDK-Micronas
HAL1562 Hall-Effect Switch Latching Type 2-Wire AEC-Q100

HAL1564 Hall-Effect Switch Unipolar inverted Type 2-Wire AEC-Q100

  • Technology: Hall
  • Polarity: Unipolar inverted
  • Swichting Points [mT] [Bon;Boff]: 4.1; 6
  • Output: Current-source (2-wire)
  • Supply Voltage Range [V]: 2.7 to 24
  • Temp. Range [C°]: –40 to +170
  • Package: SOT23, TO92UA
  • Hersteller: TDK-Micronas
HAL1564 Hall-Effect Switch Unipolar inverted Type 2-Wire AEC-Q100
